T480 Skid Steer Loader
The company's main products cover various types of small excavators, skid steer loaders and diverse attachments, which are widely used in agriculture, municipal administration, construction and logistics fields.
Classification :
Keywords :
Mini Skid Steer Loader
PRODUCT DETAILS
Built to Handle Anything
T480 Skid steer loader is built for tough jobs in tight spaces. It’s great for digging, hauling, and trenching on farms, in gardens, or warehouses. Plus, it works with attachments
like Root Grapples, Stump Grinders, and Augers, making it the go-to machine for versatility and power.
Low Fuel Consumption
This mini skid steer loaders delivers solid power while keeping fuel consumption low. Work up to 7 hours after a single refill. That means you get more done while keeping operational costs down.
Compact and Maneuverable Design
Sunlion skid steer loaders excel in tight spots where others can’t go, smoothly navigating small indoor and outdoor spaces. Their compact design fits through doorways and gates and makes loading onto trailers a breeze.
Powerful Performance
Don’t let the small size fool you! This skid steer loaders boasts a maximum lift capacity of 617 lb. (280 kg), and a dumping height of up to 91.97 in. (2336mm). It packs a punch for such a compact machine, making it ideal for a wide range of jobs.
Attachment with Fast Changes
The Sunlion compact skid steer loaders uses an easy-to-use attachment mounting system for quickly swapping between tasks. Whether you need to switch from grading to digging or hauling materials, the system ensures fast and secure attachment changes so you can stay focused on the work.
| PERFORMANCE | |
| Engine Power（HP) | 25 |
| Speed- standard(KM/H) | 6.7 |
| Track type | 180*72 |
| Rated loading capacity(KG) | 480 |
| Lifting type | Radial lift |
| Total cycle time(S) | — |
| Bucket capacity(m³） | 0.23 |
| System pressure（bar） | 210 |
| Hydraulic pump output flow（L/min） | 38 |
| Starting battery | 12V |
| Hydraulic oil tank（L) | 40 |
| Fuel tank（L) | 35 |
| Wight without bucket(KG) | 1360 |
| DIMENSION | |
| Overall operating height(MM) | 2916 |
| Height to bucket hinge pin(MM) | 2175 |
| Height to top of cab(MM) | 1560 |
| Height to bottom of level bucket(MM) | 2100 |
| Overall length without bucket(MM) | 2108 |
| Overall length with bucket(MM) | 2758 |
| Dumping angle at maximum height（°） | 40 |
| Dumping height(MM) | 1510 |
| Dumping reach(MM) | 582 |
| Rollback of bucket on ground（°） | 30 |
| Rollback of bucKet at full heirht（°） | 98 |
| Wheelbase(MM) | — |
| Ground clearance(MM) | 200 |
| Angle of departure（°） | 26 |
| Turning radius front without bucket(MM) | 1210 |
| Front turning radius with bucket(MM) | 1700 |
| Rear turning radius(MM) | — |
| Track width(MM) | 736 |
| Width(MM) | 950 |
| Bucket width(MM) | 980 |
The mini payload loader is an advanced, compact machine engineered for exceptional versatility and performance across a wide range of job sites. Designed to handle demanding lifting, digging, and loading operations in confined spaces, the mini payload loader combines powerful performance with remarkable maneuverability. It is ideal for applications in agriculture, landscaping, construction, and warehouse operations, where space efficiency and precision are key. With its durable structure and powerful hydraulic system, the mini payload loader ensures consistent output and reliability even under heavy workloads.
Built for efficiency, the mini payload loader offers impressive lifting capacity and stable operation while maintaining low fuel consumption. Equipped with a high-performance engine, it delivers strong torque and responsive control, enabling smooth operation during continuous work shifts. Its radial lift design provides an optimal balance between reach and stability, while the efficient hydraulic system allows quick response to various attachments, ensuring fast and secure task transitions.
The mini payload loader features a compact body that can easily navigate through tight spaces, narrow gates, or indoor areas, making it suitable for both small and large projects. The machine’s easy-to-operate control system and ergonomic cab design provide superior comfort and safety, reducing operator fatigue over long working hours. In addition, the quick-attach mounting system allows seamless switching between attachments such as buckets, augers, or trenchers, significantly enhancing productivity and operational flexibility.
With a robust frame, durable tracks, and optimized balance, the mini payload loader delivers smooth, stable movement even on uneven or soft terrain. Its compact width allows effortless loading onto transport trailers, while the high dumping height and strong breakout force ensure efficient material handling. Designed for modern efficiency, durability, and adaptability, the mini payload loader is a cost-effective and dependable solution for professional operators who demand high performance in a small, powerful package.
