SL10 Mini Excavator
The company's main products cover various types of small excavators, skid steer loaders and diverse attachments, which are widely used in agriculture, municipal administration, construction and logistics fields.
Classification :
Keywords :
Mini Excavator
PRODUCT DETAILS
Born for Best Value
The SL-10 mini excavator, with a digging depth of 52.76 inches and a digging radius of 102.36 feet, is highly suitable for operations such as foundation engineering and public facility pipelines. It can easily enter narrow Spaces. This cost-effective and powerful excavator is an ideal choice for DIY enthusiasts and small contractors who wish to maximize their funds. It is the most economical choice in this series and the first choice for anyone entering the mini excavator field.>5% Deeper Than Others
15% Lower Ownership Costs15% Lower Ownership Costs
With industry-low prices and minimal upkeep costsCompact body convenient and flexible
The body is compact, flexible and convenient,and suitable for various scenariosPOWERFUL PERFORMANCE IN A COMPACT DESIGN
5% Deeper Than Others
Its advanced boom design excels in tough clay, rock, and compacted soil, making it the best choice for demanding jobs.
NARROWER EXCAVATOR WIDTH
Big Performance in a Compact Design
With a total width of just 3'1", our excavator is easy to maneuver in tight urban and residential spaces. The reduced tailswing model minimizes the risk of property damage near buildings and obstacles due to its minimal swing radius.All Day Comfort
Our mini excacator keeps you comfortableall day long.It’s designed with ergonomicsin mind,so you’ve got a supportive backrest and a soft seat that’ll make your day easier.
Hydraulic Joystick Control
·The hydraulic joystick on SUNLION mini excavators ensures smooth, efficient operation. It allows precise control of attachments with minimal effort, reducing fatigue during grading and backfilling. ·Designed with the International Standards Organisation (ISO) operation mode, it ensures simplicity and ease of use, with minimal learning curve.
| MAIN DIMENSIONS | |
| Overall Length（mm） | 2820 |
| Overall Width（mm） | 943 |
| Overall Height（mm） | 2220 |
| Track Width（mm） | 180 |
| Track Length（mm） | 1257 |
| Body Width（mm） | 845 |
| SPECIFICATION | |
| Bucket Capacity | 0.017m³ |
| Engine | 科普192 7.6kw |
| Walkingl Speed | 2.1km/h |
| Rotation Speed | 8r/h |
| Platform Ground Clearance | 285mm |
| Swing Angle | 360° |
| Angle of Roll | 左45° 右55° |
| WORKING RANGE | |
| Max. Digging Radius（mm） | 2600 |
| Max Digging Depth（mm） | 1340 |
| Max. Digging Height（mm） | 1340 |
| Max. Unloading Height（mm） | 1550 |
| Min. Swing Radius（mm） | 1220 |
| Max. Digging Depth Of Dozer Blade（mm） | 210 |
| Max. Lifting Height Of Dozer Blade（mm） | 163 |
The China - made mini excavator is a remarkable piece of machinery.
With a digging depth of 1340mm and a digging radius of 2600mm, it is well - equipped for various tasks such as foundation engineering and public facility pipelines. It can dig 5% deeper than others, which is a great advantage in tough jobs like dealing with clay, rock, or compacted soil.
Its compact design is a standout feature. With an overall width of just 943mm (3'1") and a reduced tailswing, it can easily enter narrow spaces in urban and residential areas, minimizing the risk of property damage. The compact body also makes it flexible and suitable for different scenarios.
Cost - effectiveness is another key aspect. It has 15% lower ownership costs compared to others, along with industry - low prices and minimal upkeep costs. This makes it an ideal choice for DIY enthusiasts and small contractors looking to get the best value for their money. It is truly the most economical option in its series and a top choice for those new to the mini - excavator field.
The mini excavator offers comfortable operation. The operator's seat has a supportive backrest, and it is designed with ergonomics in mind for all - day comfort.
The hydraulic joystick control, following the ISO operation mode, enables smooth and efficient operation. It allows precise control of attachments with ease, reducing fatigue during tasks like grading and backfilling.
In terms of specifications, it has a bucket capacity of 0.017m³, a 7.6kw engine, and reasonable walking and rotation speeds. With a 360° swing angle and good lifting and digging capabilities, this China mini excavator is a powerful and practical choice for a wide range of applications.
